Solar panel Risen Energy RSM110-8-545M, 545W
$ 104
| Panel design | Unilateral |
|---|---|
| Country of origin | China |
| Power | 545 W |
| Photomodule type | Single crystal |
| Manufacturer | Risen Energy |
Out of stock
The Risen Energy RSM110-8-545M solar panel with a power of 545 W is a high-quality module for the construction of industrial solar power plants and large-scale energy projects. Thanks to its mono-crystalline Half-Cell technology and 9BB architecture, the panel provides high efficiency and resistance to external influences.
The model has 110 photovoltaic cells that are optimally combined to reduce energy losses and increase overall system reliability. High power output and optimal dimensions allow for efficient use of installation space, even in large projects.
The manufacturer Risen Energy is a Tier 1 company, which guarantees high product quality, strict control over production processes, and long service life of the panels.
Advantages of Risen Energy RSM110-8-545M:
- 545 W power for large commercial projects;
- Half-Cell technology to reduce energy losses;
- Mono-crystalline structure for stable energy production;
- 9BB architecture for increased durability and reliability;
- Tier 1 quality assurance from the manufacturer.
Choose Risen Energy RSM110-8-545M for stable solar power generation for many years!
| Characteristics | Meaning. |
|---|---|
| Manufacturer | Risen Energy |
| Country of origin | China |
| Model | RSM110-8-545M, 545W |
| Production technology | half-cell |
| Type of photomodule | Mono crystal (Mono) |
| Number of conductive tracks (bb) | 9 |
| Power, W | 545 |
| Voltage at max. power, V | 41.6 |
| Current at max. power, A | 13.10 |
| Short circuit current, A | 13.80 |
| No-load voltage, V | 49.5 |
| Power reserve, W | 0…+5 |
| Maximum voltage in the system, V | 1500 |
| PV module efficiency, %. | 21.3 |
| Temperature power factor, %/°C | -0.34 |
| Temperature coefficient of stress, %/°C | -0.265 |
| Temperature coefficient of current, %/°C | 0.05 |
| Operating temperature, °C | -40…+85 |
| Number of photocells, pcs. | 110 |
| Dimensions, L×W×T, mm | 2256×1133×35 |
| Weight, kg | 28.6 |
| Degree of protection of the PV module | IP68 |
| Frame | Anodized aluminum |
| Type of glass | Anti-reflective tempered glass |
| Packing method | Pallet |
| Number of panels in a pallet | 31 |
| Warranty period for the product, years | 12 |
| Warranty for 80% of output power, years | 25 |
