The Pylontech US5000 battery is an advanced energy storage solution based on lithium iron phosphate (LiFePO4) technology. This battery is characterized by high safety, long service life (over 6000 cycles at 90% discharge depth) and a modular design that allows you to increase the system capacity by connecting up to 16 batteries in parallel. The built-in intelligent BMS system provides comprehensive protection against abnormal operating conditions such as over-discharge, overcharge, over-current and temperature deviations. The Pylontech US5000 battery is an ideal choice for use in solar power systems, backup power systems and other applications requiring reliable and efficient energy storage.
Advantages:
- High level of safety: LiFePO4 technology provides excellent thermal and chemical stability.
- Durability: More than 6000 charge/discharge cycles with deep discharge.
- Flexible scaling: Up to 16 modules can be connected in parallel to increase capacity.
- Intelligent BMS: Comprehensive battery protection and optimization.
- High efficiency: Minimal energy loss during charging and discharging.
- Compact and easy to install: Standard dimensions for easy installation.
Application:
- Stand-alone and hybrid solar power plants.
- Backup power systems for home and office.
- Uninterruptible power supply systems (UPS).
- Energy storage for further use during peak load periods.
Characteristics:
| Characteristics | Value |
|---|---|
| Battery type | LiFePO4 |
| Rated voltage | 48 В |
| Capacity | 100 Ah / 4.8 kWh |
| Useful capacity | 4.56 kWh |
| Recommended charge/discharge current | 50 A |
| Maximum charge/discharge current | 100 A |
| Operating temperature range (charge) | 0°C – +50°C |
| Operating temperature range (discharge) | -10°C – +50°C |
| Dimensions (W x D x H) | 442 x 420 x 161 mm |
| Weight | 39.7 kg |
| Warranty | 7-10 years (depending on registration) |
Contact us for a consultation.
